PCX External Prox Reader
Product Features
-
Can be used as entry control
-
Green and red LEDs indicate system status when valid tag/card is presented
-
IP65 rated external proximity reader
-
Wires directly to the RS-485 BUS
-
Proximity tag or card reader
-
Switched negative for relay magnetic lock control
-
Can be used to set/unset (arm/disarm) controller
-
Complies with EN50131-1
Set Point
Can be used with either proximity tags or cards to easily set/unset the system. Green and red LEDs indicate system status when a valid tag/card is presented.
Integrated Access Control
Can be used for internal or external doors to deny unauthorised entry.
Entry Control
Need a reader to both act as a set point and access control? Entry control solves this, combining both from a single reader; using the same Pyronix proximity tags used to set and unset the system.
Weatherproof
Rated IP65, the weatherproof external proximity reader does not need to be positioned under cover therefore can be used on any external entry.
Control Panels
Setting devices technical characteristics
Intergrated prox reader |
Yes |
IP 64 rated external prox reader |
Yes |
Inputs & outputs
Onboard wired inputs |
1 |
Outputs on board |
1 |
Environmental and operating features
Certified operating temperature |
-10 a +50 °C |
Nominal operating temperature |
-10 a +50 °C |
Physical dimensions (H x W x D) |
85 x 85 x 21mm |
Electrical & battery
Operating voltage |
13,8 V (rango de 9-16 V) |
Supply current |
Máx. 90 mA a 13,8 V |
Certifications and warranty
Security Grade |
Grade 3 |
Environmental class |
IV |
EN Certificate |
EN50131-1 | PD6662 |
Certification type |
Self-certified |
Electrical conformity |
CE |
Warranty |
2 years |
